DTFP
FLAD
DTF transfer paper is mostly used on T-shirt and other clothes for pattern printing. It also can be used for Label Screen Printing. After use, the pyrograph pattern can form a hollow printing effect, that is, the part with ink is the color of the pattern, and the part without ink is the color of the fabric. It can solve some problems that the DTF PET film can not solve, such as transfer to the undegreased cotton canvas.
HOW TO USE
1. Printing images on the paper by pigment ink;
2. Dusting the hot melt powder on the paper when it is still wet;
3. Put the paper on your fabric for heat pressing with temperature on 165℃ for 10-30 seconds;
4. Peel off the paper
The technical index for our paper is as follow:
| GSM | Thickness (mm) | Ink loading (ml/m2) max |
| 80 | 0.09-0.1 | <20 |
| 120 | 0.14-0.145 | <20 |
SPECIFICATION
| Size | GSM | Fit for printer | Package (per box) | G.W (KG） |
| A4 | 80/100/120 | Desktop inkjet printng | 2000 pcs | 12-17 |
| A3 | 80/100/120 | Desktop inkjet printng | 1000 pcs | 12-17 |
| 300mm x 100m | 80/100/120 | Roll to roll inkjet printer | 6 rolls | 16-23 |
| 420mm x 100m | 80/100/120 | Roll to roll inkjet printer | 4 rolls | 15-22 |
| 600mm x 100m | 80/100/120 | Roll to roll inkjet printer | 3 rolls | 16-23 |
| 1520mm x 100m | 80/100/120 | Roll to roll inkjet printer | 1 rolls | 14-20 |
★Large-format inkjet printer and powder shaking machine:
Large-format inkjet printer and powder shaking machine can be matched to produce 1650 mm width of sticker heat transfer paper, higher efficiency!
You can also print all kinds of non-ink layer of pyrograph paper, pyrograph film and hot stamping film! unlimited varieties, lower cost!
Large-format inkjet printer
Printing width：100-1800mm
Printing head: i3200×3
Voltage: 220V
Electric current:10A
Voltage：220V
Power：10A
N.W： 300kg
SIZE: 3300*1660*90mm
Powder shaking machine
Rewinding & rewinding width：100-1800mm
The front guide plate is heated and inductively rewinding
Voltage: 220V
Power：4.92KW
N.W： 540kg
SIZE: 2045*2241*1076mm
